MNEPV30-300-1PP DISJONCTEUR PV 300V 30A

MNEPV30-300-1PP 30A 300VDC DIN Rail Mount Breaker

40-411-25348

Prix détail / Retail Price

CA $44.95

Statut d'inventaire / Inventory Status

Article inventorié / Stocked Item

Qty:

Description

Description

MidNite's breakers are rated to break the full rated load at the rated voltage repeatedly, with NO DAMAGE. Always use a properly sized breaker for disconnecting.

All MidNite circuit breakers can be used at 100% rated current when mounted in a MidNite enclosure.
Breaker Torque Value: 20 In-Lbs (2.3NM)

POLARIZED
Environmental Rating - Type 1 (Indoor)
DC Voltage Rating - 150VDC
Wire Size Range - 14 to 6 AWG
Width - 0.5 inches (13mm)
Number of poles - 1
Listed for US & Canada when used in MidNite Solar enclosures

Specifications

Specifications

Ampères / Amps

30

Marque / Brand

MidNite Solar

Hauteur / Height

3.9"/98.4mm

Garantie / Warranty

60 mois
60 months

Largeur / Width

0.5"/12.8mm

Numéro de pièce/modèle / Part/Model Number

MNEPV30-300-1PP

Marques de certifications / Regulatory Certification Marks

UL 489A, CSA C22.2

Volts

300

Poids / Weight (kg)

0.1100
